Garmin TT 15 Mini Dog Device

0 out of 5


Free USPS Priority Mail Shipping

Collar includes color choice of e-collar reflective strap and an e-collar nameplate.

View cart


The Garmin TT 15 Mini Dog Device is a top-mounted, high-sensitivity GPS/GLONASS receiver, that uses 18 levels of continuous and momentary stimulation, plus audible tone and vibration activated from Alpha 200i, Alpha 200,  Alpha 100, Alpha 10 or the PRO 550 Plus. Compatible with Astro® 430 and 320 for tracking only.

Rugged and water-resistant to 10 meters, the tracking and training dog device with collar is tough enough to run wherever your dog runs, up to 4 miles away. The stimulation features let you train each dog separately — traditional stimulation allows you to make quick changes (low, medium or high) within a predetermined stimulation level (1-6), whereas linear stimulation allows progressively more stimulation from levels 1 to 18. You can remotely operate the LED beacon lights, built in to the dog device, to help locate your dog in low-light conditions.

Cartridge Brass Nameplate with Easy to Read 3/32″ Characters

  • Lines 1-8 have 17 characters maximum including spaces.
  • Nameplates only use the following characters: 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, A, B, C, D, E, F, G, H, I, J, K, L, M, N, O, P, Q, R, S, T, U, V, W, X, Y, Z, –
  • Nameplates are made from cartridge brass.
  • The nameplate measures 2 3/4″ long and 1 1/4″ high.
  • All nameplates are finished with a black Laquer-Stik fill-in-paint to emphasize the characters.

We customize the tag with any information, provided you use the characters listed above. The most popular information is:

Line 1:  Your Name

Line 2:  Your City & State

Line 3:  Home phone

Line 4:  Cell phone

Lines 5-8: Additional Information


  • Track and Train with one collar using Alpha 100 handheld or Pro 550 Plus handheld. Tracking only with the Astro 430 handheld.
  • 18 levels of continuous and momentary stimulation – plus audible tone and integrated LED light beacons.
  • TT 15 Mini collar is equipped with a top-mounted, high-sensitivity GPS and GLONASS receiver for increased signal reception.
  • Rechargeable Li-ion batteries with a battery life of approximately 24-48 hours depending on update rate.
  • Dog rescue mode switches TT 15 Mini to a slower update rate to prolong battery life.
  • Rugged and waterproof design (10m).
  • Can start/stop VIRB camera recording based on user command from Alpha 100 handheld
  • Includes 2 lengths (long and short) of removable, stainless steel, insulated contact points for reliable performance in wet conditions and extended comfort for any coat length.

In The Box

  • TT 15 Mini dog device with rechargeable lithium-ion battery
  • 3/4-inch red collar strap
  • Charging clip
  • AC adapter
  • Vehicle power cable
  • Contact point set with wrench
  • Garmin TT 15 Mini Dog Device Manual

To learn more about the Garmin TT 15 Mini Dog Device features read the Owner’s Manual.

Video: Battery Replacement

Video: Troubleshooting GPS Reception Issues

Video: Updating Your TT15/TT15 Mini

  • Model: TT15Mini
  • Manufactured by: Garmin
  • Unit dimensions (WxHxD): 3.1″ x 1.8″ x 1.4″
  • Weight: 5.6 oz (without collar strap); 7.5 oz total weight (with collar strap)
  • Battery type: rechargeable lithium-ion pack; user replaceable
  • Battery life: 16-30 hours
  • Range: 4 miles
  • Interface: USB
  • Waterproof: 1 ATM (10 meters)
  • Neck size: Minimum of 9.5″ (24 cm) in circumference
  • High-sensitivity GPS/GLONASS receiver
  • GPS antenna: top, black
  • Stimulation/Vibration/Tone
  • LED beacon lights
  • Rescue mode
  • Sleep mode
  • Frequency mode: MURS
  • Compatible with the Astro 320, Astro 430, PRO 550 Plus and the Alpha 100. Note: TT15Mini can be configured for operation with either handheld but cannot be tracked simultaneously by both the Astro and the Alpha 100
  • Replaceable collar straps
  • Collar strap width – 3/4″
  • TT 15 mini dog device with rechargeable lithium-ion battery
  • 3/4-inch red collar strap
  • Charging clip
  • AC adapter
  • Vehicle power cable
  • Contact point set with wrench
  • Manual
